i2rA AR SF Specifications
StoneyCNC is the EU COMPETENCE Center for the 40Robotics and i2r range of CNC routers | End user and Distributor support HQ
Machines stocked and available from our HQ in Dublin in EURO!!
Machines shipped from Dublin to UK in £, with UK VAT invoice, all customs processes fulfilled. No customs process required on the UK side.
| STONEYCNC i2rA 4(2x2) 6(2x3) 8(2x4) | i2rA specifications | |
| Travel in X axis ALL | =610mm | |
| Travel in Y axis i2rA4(2x2) | =610mm | |
| Travel in Y axis i2rA6(3x2) | =915mm | |
| Travel in Y axis i2rA8(4x2) | =1220mm | |
| Travel in Z axis | =153mm | |
| Overall footprint | ||
| 4(2x2) | = 995L x 950W x 770H (mm) | |
| 6(2x3) | = 1300L x 950W x 770H (mm) | |
| 8(2x4) | = 1600L x 950W x 770H (mm) | |
| Dimensions when shipped crated | 4(2x2) | = 1070 x 990 x 840 (mm) |
| 6(2x3) | = 1347 x 990 x 840 (mm) | |
| 8(2x4) | = 1651 x 990 x 840 (mm) | |
| Machine weights | ||
| 4(2x2) | = 120 kg | |
| 6(2x3) | = 135 kg | |
| 8(2x4) | = 150 kg" | |
| Bottom of collet to Tslot table height | 165mm | |
| Rapid Feed rate | 8000mm/min in XY | |
| 2000mm/min in Z" | ||
| Spindle Options | High power water cooled HF spindle | |
| Software Compatibility | Ethernet controller running UCCNC software | |
| Drive system Electronics | high power stepper motors | |
| Limit and homing sensors | Inductive sensors running on 12V DC on XY and Z | |
| Drive system | 16mm Ballscrew drives on XY and Z | Repeatability within 0.05mm | |
| Thrust support | Double angle contact bearings preloaded at thrust end of ballscrew support | |
| Linear motion system | Profiled linear rails on all axes. | |
| Cable management | Full cable management on all axes | |
| Core components | Steel base | Cast Y cross member and up stands | Custom Aluminium extrusion bridge | |
| Machine bed | Tslot table with integrated MDF spoil-board as standard | |
| Tool lenght sensing | Configured for conductive tool touch off sensing |
2022 update: We have rebranded our “AXIOM” line of CNC routers to “i2rA” in line with the Stoney CNC i2r (imagination to reality) brand.
